SH 860P

Heavy-Duty Full-Motion TV Wall Mount

Screen Size50"~90"

Max Vesa800x600mm

Weight Capacity75kg

Profile to Wall69-635mm

Tilt Range+5° ~ -15°

Tags: TV Wall Mounts, TV Mounts, Wall Mounts , TV Brackets , Low Profile TV Wall Mount, TV Stand, TV Wall Mount In UAE , Quality TV Wall Mount,Full Motion Double Arm Mounts, Heavy-Duty Full-Motion TV Wall Mount

Overview

Product Category	Full-Motion TV Wall Mount
Rank	Standard
Material	Steel
Pipe Size	40x25x1.5mm (1.6"x0.98"x0.059")
Surface Finish	Powder Coating

Strength Tested	2 Times Approved
Profile	69-635mm (2.7"~25")
Tilt Range	+5°~-15°
Swivel Range	+60° ~ 60°
Screen Level	+3° ~ -3°

Product Category	Full-Motion TV Wall Mount
Rank	Standard
Material	Steel
Pipe Size	40x25x1.5mm (1.6"x0.98"x0.059")
Surface Finish	Powder Coating

Features

Wide CompatibilitySupports most 50"–90" flat and curved TVs with VESA & Universal mounting up to 800x600mm.
Strong BuildHeavy-duty steel construction with 75kg load capacity and dual-stud solid wall installation.
Flexible AdjustabilityOffers +5° to -15° tilt, ±60° swivel, and ±3° screen leveling.
Extended ReachFull-motion extension range of 69–635mm (2.7"–25") for optimal viewing angles.
Convenient FeaturesIncludes cable management, detachable panel, and a hook-on bubble level for easy setup.

Description

The SH 860P Heavy-Duty Full-Motion TV Wall Mount is designed for large flat and curved screens from 50" to 90". Built from strong steel with a durable powder-coated finish, it supports up to 75kg. With a full-motion profile of 69–635mm, it offers ±60° swivel, ±15° tilt, and ±3° screen leveling. Compatible with VESA & Universal mounts, it features cable management, a detachable panel, and includes a hook-on bubble level for precise installation.
